LC Programming – continued from last page.
Scanner #1 is the internal 6000-07 Hipot/Leakage Current Scanner.
Channels 1 and 3 are available on Scanner #1. CH1 is used to provide the voltage to the
DUT to power it on. CH3 can be set to L or X.
STEP SETTING
01. Test Step
02. Test Mode
03. Device
1
X
10. Test Time
11. CHNL (H-L)
PRESS NUMBER KEYS
Press [3] once to set Channel 3 to L (Low)
Press the function key [EXIT] to return to LC program menu.
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___7___ ".
The 7-step example is complete.
Press [MENU] to exit program mode.
Set Preset (¶2.6)
Perform Offset (¶2.7.1)
Perform Get Cs (¶2.7.2)
Press [MEMORY] then [STORE].
Press DOWN arrow [⇓] to move backlit box to selected location (1-100).
Press [ENTER]
Use numeric keys to give memory location a name (up to 13 alpha-numeric characters).
Complete memory instructions are contained in ¶ 2.5
Press [ENTER] when finished.
Press [MENU] then [TEST].
Operation
www.valuetronics.com
: 7
: LC
: UL2601
SETUP SCANNER - 1
2 3 4 5 6 7 8
X X X X X X X
3.0s
OFF
Remote Lock
NEXT BOX
EXIT
Offset Error
150799 Rev A3
In LC mode,
Use Numeric Keys then [ENTER]
Use the Numeric Key that corresponds to the Channel #
The Numeric Key acts as a toggle switch: X, H or L
Program the scanner channels
X = Not used
H = High (High voltage/current applied to this channel)
L = Low (This channel is the return)
Use Function Key [NEXT BOX] to setup next scanner
Use Function Key [EXIT] to exit scanner setup
