The PASS ON setting provides the option of programming a pass relay closed time after
a PASS condition at the completion of the test. When set to CONT, the relay opens at
start of next test or when unit is reset. To access Pass-ON, enter System Setup by
pressing [MENU], [1] and the [↓] or [↑] arrow on the keypad so the backlit box is to the
right of Pass-ON. Use the numerical keys then [ENTER] to enter the time in seconds.
The range for PASS ON is 0.1 – 99.9sec or CONT (continuous) and the instrument
default value is CONT. The beeper will also sound for the duration of the Pass ON time
to indicate the test is complete.
2.3.1.7
This function is valid for the Guardian 6100 Plus line leakage test only. The Use Source
function is used when the G6100 Plus instrument is connected to a Chroma 6400 Series
AC Power Source. It is valid in simulated leakage current mode only and requires an RS-
232 connection to the 6400. The source is set ON or OFF. The default setting is OFF.
LC Mode with USE SOURCE = OFF
