2.3.1.3
This setting is valid for Guardian 6100 Plus line leakage test only. Compensate is the LC
input voltage compensation in which a correction (% value) can be added to better
simulate what the true line leakage would be. The simulation correction value can be
programmed in whole number increments of ±(5-50%). Use the numerical keys then
[ENTER] to enter a compensate value in percent. The range is 5-50% and the default
setting is 20%.
2.3.1.4
The Automatic Gain Control (AGC) circuit is used to keep the output signal of a circuit
constant as the amplitude of the input signal varies. The Guardian 6000 Plus has two
Gain Control circuits: hardware and software. See Table 2-3 for gain control functions
based on output voltage.
50 – 5kV AC
50 – 499V DC
500 – 6kV DC
50 – 1000V DC (IR)
DC 50V AGC is the hardware gain control for DC voltages below 500V. To access DC
50V AGC, enter System Setup by pressing [MENU], [1] and the [↓] or [↑] arrow on the
keypad so the backlit box is to the right of DC 50V AGC. Use the function key [ON] or
[OFF] to turn the automatic gain control circuit ON or OFF. The default setting is OFF.
Operation
www.valuetronics.com
Compensate
SYSTEM SETUP
01.
Contrast
02.
Beeper Vol.
03.
Compensate
04.
DC 50V AGC
05.
Discharge - V
06.
Pass ON
07.
Use Source
08.
After Fail
09.
AC Offset
10.
LC Offset
11.
IEEE-488.1
5 - 50%
DC 50V AGC
Table 2-3: AGC & Output Voltage
Output
Hardware AGC
SYSTEM SETUP
01.
Contrast
02.
Beeper Vol.
03.
Compensate
04.
DC 50V AGC
05.
Discharge - V
06.
Pass ON
07.
Use Source
08.
After Fail
09.
AC Offset
10.
LC Offset
11.
IEEE-488.1
ON/OFF
:
17
:
HIGH
:
20%
:
ON
:
3.10kV
:
1.0s
:
OFF
:
STOP
:
0.5mA
:
0.00mA
:
ON
Remote
Lock
Offset
Software AGC
ON
Programmable
(Default ON)
OFF
Programmable
(Default ON)
ON
Programmable
(Default ON)
None
Always On
:
17
:
HIGH
:
20%
ON
:
ON
:
3.10kV
:
1.0s
:
OFF
OFF
:
STOP
:
0.5mA
:
0.00mA
:
ON
Remote
Lock
Offset
150799 Rev A3
Error
DC 50 V AGC
NA
Programmable
(Default OFF)
NA
NA
Error
Page 37 of 177
