QuadTech Guardian 6100 Plus Instruction Manual page 146

:CHANnel (@ <Box#> (<channel list>))
:GB
:LEVel <numeric value>
Command: :SOURce:SAFEty:STEP<n>:GB:LEVel <numeric value>
This command sets the DC voltage level for the selected step.
<numeric value> is 3 to 30 (40 w/option) and the unit is amperes.
:LEVel?
Command: :SOURce:SAFEty:STEP<n>:GB:LEVel?
This command queries the current level for the selected step.
:LIMit
Page 146 of 177
www.valuetronics.com
:TEST <numeric value>
Command: :SOURce : SAFEty : STEP <n> : IR : TIME : TEST
This command sets the test time for the selected step.
<numeric value> is 0, 0.3 to 999 and the unit is seconds. 0 = Continuous
:TEST?
Command: :SOURce : SAFEty : STEP <n> : IR : TIME : TEST?
This command queries the test time for the selected step.
:HIGH <channel list>
Command: :SOURce : SAFEty : STEP <n> : IR : CHAN : HIGH (@ Box#
(<channel list>))
This command sets the high scan channels for the selected step.
:HIGH?
Command: :SOURce : SAFEty : STEP <n> : IR : CHAN : HIGH?
This command queries the high scan channels for the selected step.
:LOW <channel list>
Command: :SOURce : SAFEty : STEP <n> : IR : CHAN : LOW (@ Box#
(<channel list>))
This command sets the low scan channels for the selected step.
:LOW?
Command: :SOURce : SAFEty : STEP <n> : IR : CHAN : LOW?
This command queries the low scan channels for the selected step.
Note: Channel list must be 0 (zero) when no channels are set high or low.
:LIMit:HIGH <numeric value>
Command: :SOURce:SAFEty:STEP<n>:GB:LIMit:HIGH <numeric value>
This command sets the high resistance limit for the selected step.
<numeric value> is 0 to 510 and the unit is milliohms
:LIMit:HIGH?
Command: :SOURce:SAFEty:STEP<n>:GB:LIMit:HIGH?
Return Value: +1.000000E-03
This command queries the high resistance limit for the selected step
150799 Rev A3 Interface
