There are 100 locations in memory and up to 50 test steps may be stored in any one
location for a total memory block of 500. There are 10 memory locations listed per page
on the display. [NEXT PAGE] will move the backlit box to the top of the next page in
memory. The [↑] and [↓] arrows move the backlit box UP and DOWN the displayed
page.
To access MEMORY, press the [MENU] function key at the top left hand corner of the
keypad and press the function key [MEMORY].
functions: Store, Recall and Delete. Refer to Figure 2-16.
Location #:
1-100
To access any of these 3 functions, press the function key that corresponds to the desired
parameter.
The [↑] and [↓] arrows move the backlit box UP and DOWN the displayed page.
2.5.1 Storing a Test
Prior to storing a test make sure all PRESET parameters have been set and all steps have
The preset values will be stored with the test setup. The Offset and Get Cs functions
should be performed, so that the Offset and Get Cs values can also be stored with the test
setup. Note however that the Offset and Get Cs values are only valid for the particular
connection to DUT and known DUT, respectively. Anytime the test leads, fixture or
standard DUT changes, then the Offset and Get Cs functions must be performed again.
Operation
www.valuetronics.com
MEMORY
# of Steps: 1-50
MEMORY SETUP
1. ( 0) :
2. ( 2) : 4N56122456789
3. ( 7) : EXAMPLE
4. ( 6) : test-1
5. (12) : 1-B
6. ( 0) : __
7. ( 0) : __
8. ( 0) : __
9. ( 0) : __
10. ( 0) : __
Location Name: 1-13 alpha-numeric characters
STORE
RECALL
DELETE
NEXT PAGE
Remote Lock Offset Error
Figure 2-16: MEMORY
Note:
Note:
been programmed.
150799 Rev A3
Within MEMORY there are 3
Store Test to selected Location
Recall selected Location
Delete selected Location
View/change next 10 Locations
Page 97 of 177
