2.4.5 Programming a DC Hipot Test
In a DC hipot test, high DC voltage is applied between the DUT's operating circuits and
chassis ground to determine if/when a breakdown will occur in the insulation of the DUT.
The current is measured between the DUT insulation and ground. A high limit is
required in a DC test. The high limit is the maximum allowed value for the test to be
considered a PASS. If the measured value is higher than the high limit the test is
considered a FAIL.
If not already in PROGRAM mode:
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
If continuing example:
* Press the function key [UP] or [DOWN] to select Step # = 5
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT STEP
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT MODE
Press the function key [DC] to select mode = DC Hipot
Continued on next page.
