QuadTech Guardian 6100 Plus Instruction Manual page 23

Reference
Number
Figures 1-1
and 1-2
1
2
3
4
5
6a
6b
6c
6d
7
8
9
10
11a
11b
11c
12
13
14
Introduction
www.valuetronics.com
Table 1-1 : G6100 Plus Front Panel Controls and Indicators
Name Type
POWER White Toggle Switch
Display 320x240 LCD
Cal Enable Recessed switch
Update Recessed switch
Keypad White Push Buttons
1, ABC White Push Button
2, DEF White Push Button
3, GHI White Push Button
4, JKL White Push Button
5, MNO White Push Button
6, PQRS White Push Button
7, TUV White Push Button
8, WXYZ White Push Button
9, - White Push Button
0 White Push Button
White Push Button
.
CLR White Push Button
↓
White Push Button
↑
White Push Button
ENTER Yellow Push Button
Drive+ Red Female Recptacle
Sense+ Red Female Recptacle
Sense- Black Female Recptacle
Drive- Black Female Receptacle
PASS Green LED
FAIL Red LED
OUTPUT White Female Receptacle
DANGER Red LED
MENU White Push Button
PRINT White Push Button
LOCAL White Push Button
Function Keys White Push Button
START Green Push Button
STOP Red Push Button
Function
Applies AC power to unit, 0=OFF, 1=ON
Indicates step, mode, limits, test setup, test result
Used by Qualified Service Personnel for unit calibration.
Used by Qualified QT Personnel for unit service.
Enter data to program tests
Alpha-numeric key: 1-A-B-C-a-b-c
Alpha-numeric key: 2-D-E-F-d-e-f
Alpha-numeric key: 3-G-H-I-g-h-i
Alpha-numeric key: 4-J-K-l-j-k-l
Alpha-numeric key: 5-M-N-O-m-n-o
Alpha-numeric key: 6-P-Q-R-S-p-q-r-s
Alpha-numeric key: 7-T-U-V-t-u-v
Alpha-numeric key: 8-W-X-Y-Z-w-x-y-z
Alpha-numeric key: 9, - (hyphen)
Numeric key: 0
Decimal key
To cancel parameter number and input again
To move down a menu
To move up a menu
To enter test parameters
High Current Terminal (Driver) for Ground Bond Test
High Voltage Terminal (Sense) for Ground Bond Test
Low Voltage Terminal (Sense) for Ground Bond Test
Ground Reference for ALL Tests
When lit, indicates PASS result of programmed test
When lit, indicates FAIL result of programmed test
High Voltage Terminal (AC/DC Hipot & IR)
When lit, indicates high voltage output at test terminals
Main Menu & Sub-menus, Program, Memory, Preset, Test
When Printer interface is installed and PRINT is pressed:
In PROGRAM mode: print out test parameters
In TEST mode: print out test results
In REMOTE status, pressing LOCAL returns G6100Plus
to LOCAL mode
Select Sub-menus and enter test parameters
Starts a test and applies high voltage to the Test Terminals
Stops the test in progress. Reset function : Stop MUST be
pressed before green Test button.
150799 Rev A3 Page 23 of 177
