2.7.3.4
Use both leads of the G-15 Ground Continuity Lead Set. The black banana plug and
spade lug connect to the (-) side of the output terminals and product. The red banana
plug and spade lug connect to the (+) side of the out put terminals and product. Make the
connection to the Drive + and Drive – terminals with the spade lug positioned behind the
nut. The S-02 Cable Lead Set connects the product to G6100 Plus unit through a two
lead set. Connect the white plug to HV OUTPUT. The black banana plug with retaining
bracket for connection to the Drive- terminal is not needed when using the G15 with the
S02.
STOP
START
ON
1
0
OFF
NOTE:
Make the connection to the
DRIVE+ and DRIVE-
terminals with the spade lug
behind the nut. Use the
Bushing Driver Tool included
to secure the nut as shown
here.
Figure 2-29: Connection for Hipot and GB Test (Using S02 & G15 Lead Sets)
Page 116 of 177
www.valuetronics.com
G15 and S02 Lead Sets
QuadTech
Guardian 6100 Plus
Electrical Safety Analyzer
DRIVE+ and DRIVE-
Output Terminals
Screw SPADE between bolt
and second connector
SPADE lug
150799 Rev A3
MENU PRINT LOCAL
1 2 3
4 5 6
7 8 9
0 . CLR
ENTER
CAL UPDATE
Red
Spade
Lug
to
Drive+
Red Alligator Clip
to Case of DUT
DUT
TM
Twin
Por t s
W hite
DANGER
HIGH
Custom
VOLTAGE
Banana Plug
CAUTION!
!
Max: 5kVAC
to OUTPUT
6kVDC
OUTPUT
PASS FAIL
Drive Sense Sense Drive
+ -
Black
Spade
Lug
to
Red Black
Drive-
Banana Banana
Plug Plug
to to
Sense+ Sense-
Black Alligator Clip
to DUT GND (-)
GND (-)
(+)
HV
Alligator
HV(+)
Operation
Red
Clip
to
