Press the function key [3 -230 kHz] to set arc filter frequency = 3 – 230kHz
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set test time = 3.0s
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set ramp time = 3.0s
Press DOWN arrow [⇓]
Display reads: "11. CHNL (H-L) : OFF"
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___5___ ".
Press the function key [UP] to select Step # = 6
Press DOWN arrow [⇓]
Press the function key [IR] to select mode = Insulation Resistance
Press DOWN arrow [⇓]
Press [1][.][0][ENTER] to set voltage = 1.000kV
Press DOWN arrow [⇓]
Press [1][0][0][0][0][ENTER] to set low resistance limit = 10,000MΩ
Press DOWN arrow [⇓]
Press [0][ENTER] to set high resistance limit = OFF
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set test time = 3.0s
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set ramp time = 3.0s
Press DOWN arrow [⇓] Display reads: "8. CHNL (H-L) : OFF"
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___6___ ".
Press the function key [UP] to select Step # = 7
Press DOWN arrow [⇓]
Press the function key [LC] to select mode = Leakage Current
Press DOWN arrow [⇓]
Press the function key [UL2601] to select device = UL2601 body model
Press DOWN arrow [⇓]
Press the function key [NORMAL] to select line input = Normal
Press DOWN arrow [⇓]
Press the function key [OPEN] to select ground switch = Open
Press DOWN arrow [⇓]
Press the function key [L-G] to set meter connection = Line to Ground
Press DOWN arrow [⇓]
Press [1][0][.][0][ENTER] to set high curent limit = 10.00mA
Press DOWN arrow [⇓]
Press [0][ENTER] to set low curent limit = OFF
Press DOWN arrow [⇓]
Press the function key [SETUP] to setup the power measurement
