Program the Scanner Channels
Continuing the example, there are 4 DUTS connected to each of the 5000-01 external
scanners as illustrated in Figure 3-13. The internal 6000-07 scanner is not used in this
example. Program an OSC and an AC test and set CH1, 3, 5 & 7 to "L" and CH2, 4 6 &
8 to "H" for both Scanner #2 and #3.
In MAIN MENU press [PROGRAM] to enter the Program Menu. The backlit box is now
again at the top of the list adjacent to "Test Step: ___1___ ".
Press DOWN arrow [⇓]
Press the function key [PAGE1/2] then [OSC] to select mode = Open/Short Circuit
Press DOWN arrow [⇓]
Press [5][0][ENTER] to set the Open Check = 50%
Press DOWN arrow [⇓]
Press [3][0][0][ENTER] to set the Short Check = 300%
Press DOWN arrow [⇓]
Display reads: "5. CHAN (H-L) : OFF"
Press the function key [SETUP]. Leave Scanner 1 OFF
Press the function key [NEXT BOX] to go to "Setup Scanner – 2"
Press [1] until L is selected.
Press [2] until H is selected.
Press [3] until L is selected.
Press [4] until H is selected.
Press the function key [NEXT BOX] to go to "Setup Scanner – 3"
Press [1] until L is selected.
Press [2] until H is selected.
Press [3] until L is selected.
Press [4] until H is selected.
Press the function key [EXIT]
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___1___ ".
Press the function key [UP] to select Step # = 2
Press DOWN arrow [⇓]
Press the function key [AC] to select mode = AC Hipot
Press DOWN arrow [⇓]
Press [1][.][5][0][0][ENTER] to set voltage = 1.500kV (1500V)
Press DOWN arrow [⇓]
Press [0][.][5][0][0][ENTER] to set the high current limit = 0.500mA
Press DOWN arrow [⇓]
Press [0][ENTER] to set low current limit = OFF
Press DOWN arrow [⇓]
Press [0][ENTER] to set arc current limit = OFF
Press DOWN arrow [⇓]
Interface
www.valuetronics.com
Press [5] until L is selected.
Press [6] until H is selected.
Press [7] until L is selected.
Press [8] until H is selected.
Press [5] until L is selected.
Press [6] until H is selected.
Press [7] until L is selected.
Press [8] until H is selected.
