QuadTech Guardian 6100 Plus Instruction Manual page 54

GB Programming – continued from last page.
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
1 - 60A
Press [3][0][ENTER] to set current = 30A
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
0.1 - 510.0 mΩ
Press [1][0][0][ENTER] to set high limit = 100mΩ
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
0 - 100.0 mΩ
Press [0][ENTER] to set low limt = OFF
Continued on next page.
Page 54 of 177
www.valuetronics.com
: 1
: GB
OFF
:
: 100.0mΩ
: OFF
: 3.0s
: OFF
OFF
:
Remote Lock Offset
: 1
: GB
: 30.0A
100.0mΩ
:
: OFF
: 3.0s
: OFF
OFF
:
Remote Lock Offset
: 1
: GB
: 30.0A
: 100.0mΩ
OFF
:
: 3.0s
: OFF
OFF
:
Remote Lock Offset
Use Numeric Keys then [ENTER]
Enter the Test Current in amperes (A)
1 - 60A, 0 = OFF
1 - 30A
40A - 60A with optional transformer
Error
Use Numeric Keys then [ENTER]
Enter the High Limit in milliohms (mΩ)
0.1 - 510.0 mΩ
Error
Use Numeric Keys then [ENTER]
Enter the Low Limit in milliohms (mΩ)
0 - 100.0 mΩ, 0 = OFF
Error
150799 Rev A3 Operation
