2.6.12 Start Wait
The Start Wait time is a delay time – after connection to the device is made and before
current is applied to begin the ground bond test. This feature is normally used in a
probing application. For example: If a 2 second start wait time is programmed, once the
continuity between high and low GB connections is made, the G6100 Plus unit waits the
2sec programmed start time then applies current to the DUT.
To access Start Wait, press [PRESET] and then the [↓] or [↑] arrow on the keypad so the
backlit box is to the right of Start Wait. Use the function keys [UP] or [DOWN] to
increase or decrease the time the instrument will wait before a GB test. The Start Wait
range is 0, 0.1 – 99. 9 seconds and the default setting is 0 (OFF).
When START WAIT is ON, the G6100 Plus instrument will start if contact is made with
2.7
To access TEST, press the [MENU] function key at the top left hand corner of the keypad
and press the function key [TEST]. There are 2 functions within the TEST menu: Offset
and Get Cs. Refer to Figure 2-21. If KEY LOCK is ON, the RECALL button is
accessible from the Test Menu.
MAIN MENU
1 SYSTEM
2 OPTION
3 CALIBRATION
4 KEY LOCK
5 NEW SECURITY CODE
6 FAIL LOCK
7 ERROR LOG
To access either of these 2 functions, press the function key that corresponds to the
desired parameter.
Page 106 of 177
www.valuetronics.com
PRESET SETUP
01. Pass Hold
02. Step Hold
03. AC Freq.
04. GB Freq.
05. IEC - 601
06. GB Voltage
07. Auto Range
08. Soft AGC
09. Part No.
10. Lot No.
11. Serial No.
12. Start Wait
0, 0.1 - 99.9s 0=OFF
The START WAIT function is ACTIVE until the [STOP] button is pressed.
TEST
MEMORY
PRESET
PROGRAM
TEST
Remote Lock Offset Error
: 0.5 sec
: 0.3 sec
: 64 Hz
: 60 Hz
: OFF
: 15.0 V
: OFF
: ON
EX2000
:
092005
:
AN456000
:
OFF
:
Remote Lock
CAUTION
the test leads.
TEST
MODE
Standby
Figure 2-21: TEST SETUP
