QuadTech Guardian 6100 Plus Instruction Manual page 78

LC Programming – continued from last page
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Device
04. Line Input
05. GB Switch
06. Meter
07. High Limit
08. Low Limit
09. Power
10. Test Time
11. CHNL (H-L)
PRESS FUNCTION KEY
Press the function key [L-G] to set the LC Meter = Line to GND
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Device
04. Line Input
05. GB Switch
06. Meter
07. High Limit
08. Low Limit
09. Power
10. Test Time
11. CHNL (H-L)
0.0001 - 10mA
Press [6][.][0][ENTER] to set high curent limit = 6.000mA
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Device
04. Line Input
05. GB Switch
06. Meter
07. High Limit
Low Limit
08.
09. Power
10. Test Time
11. CHNL (H - L)
0 - 10mA
Press [0][ENTER] to set low curent limit = Off
Continued on next page.
Page 78 of 177
