Use the [EXIT] key to exit Print Setup and return to Option Menu.
2.3.2.5
If an optional High Current transformer is being used, use GB-C RATE to set the current
ratio for the Ground Bond test. To access GB-C Rate Setup, enter the Option Menu by
pressing [MENU], [2] and then the function key [GB-C RATE].
[DOWN] function key to select the current ratio = 30:30, 30:40, 30:45 or 30:60. The
default value is 30:30. This ratio must be set prior to programming if using the optional
transformer.
Use the [EXIT] key to exit GB-C Rate Setup and return to Option Menu.
2.3.3 CALIBRATION
Refer to Section 4, Sevice & Calibration for the calibration procedure. Calibration of the
Guardian 6100 Plus is recommended on an annual basis. The instrument can be
calibrated by a qualified service person if traceable calibration equipment and standards
are available.
The CALIBRATION function is password protected. To access CALIBRATION, press
the [MENU] function key at the top left hand corner of the keypad and press the
numerical key [3]. Press [7][9][3][1][ENTER] to enter calibration mode. To protect the
accuracy of the instrument, the Calibration Password is different than the User Password.
2.3.4 KEY LOCK
When KEY LOCK is ON, the LOCK status LED on the display is illuminated and the
MEMORY and TEST functions are operational.
[MENU] function key at the top left hand corner of the keypad and press the numerical
key [4]. Use the numerical keys and press [0][0][0][0][ENTER]. To de-activate KEY
LOCK, press [MENU] [4] [0][0][0][0][ENTER]. The LOCK LED will go off and all
functions will be operational.
Note: If the Security Code has been changed, [0][0][0][0][ENTER] will not work for
KEY LOCK. Use the new Security Code.
When KEY LOCK is ON, the TEST menu will now display RECALL so that memory
may easily be recalled. When the G6100 Plus is powered down with KEY LOCK ON, it
will boot to the TEST menu when powered back ON.
Operation
www.valuetronics.com
GB-C RATE
GB CURRENT RATE SETUP
GB CURRENT RATE: 30 : 60
You can use function key
to select.
150799 Rev A3
UP
DOW N
EXIT
Remote Lock Offset Error
To activate KEY LOCK, press the
Use the [UP] or
Current Ratio
30 : 30
30 : 40
30 : 45
30 : 60
