QuadTech Guardian 6100 Plus Instruction Manual page 132

Page 132 of 177
www.valuetronics.com
13 1
14 2
15 3
16 4
17 5
18 6
19 7
20 8
21 9
22 10
23 11
24 12
Guardian 6100 Plus
IEEE-488 Interface: Rear Panel View
Figure 3-6: IEEE-488 Interface PIN Configuration
DIO5 13
DIO6 14
DIO7 15
DIO8 16
REN 17
18
19
20
21
22
23
24
Guardian 6100 Plus
IEEE-488 Interface: PIN Configuration
150799 Rev A3
1 DIO1
2 DIO2
3 DIO3
4 DIO4
5 EOI
6 DAV
7 NFRD
8 NDAC
9 IFC
10 SRQ
11 ATN
12
Interface
