4.3.1 Calibration Procedure
Table 4-2 details the two-part calibration procedure for the G6100 Plus instrument.
DEVICE CALIBRATION
CAL 1
CAL 2
CAL 3
CAL 4
CAL 5
CAL 6
CAL 7
CAL 8
CAL 9
CAL 10
CAL 11
CAL 12
CAL 13
CAL 14
CAL 15
CAL 16
CAL 17
CAL 18
CAL 19
CAL 20
CAL 21
CAL 22
CAL 23
CAL 24
CAL 25
LC BOARD CALIBRATION
CAL 1
CAL 2
CAL 3
CAL 4
CAL 5
CAL 6
CAL 7
CAL 8
CAL 9
CAL 10
Page 166 of 177
www.valuetronics.com
Table 4-1 : Calibration Equipment
Equipment
AC/DC High Voltage Voltmeter
AC/DC Current Meter
IR Standards Box
1GΩ Resistance Standard
100MΩ Resistance Standard
10MΩ Resistance Standard
10MΩ Resistance Standard
50kΩ Resistance Standard
150kΩ Resistance Standard
420kΩ Resistance Standard
Table 4-2 : Calibration Parameters
TEST
ACV 5kV
ACV 5kV
DCV 6kV
DCV 6kV
IRV 1kV
IRV 1kV
ACA 3mA
ACA 3mA
ACA 40mA
ACA 40mA
DCA 3mA
DCA 3mA
DCA 12mA
DCA 12mA
GBA 30A
GBA 30A
GBV 8V
GBV 8V
AC Arc 40mA
DC Arc 12mA
IRA 100
IRR 250V
IRR 500 V
IRR 500 V
IRR 1000V
LC 1V
LC 1V
LC 10V
LC 10V
LCV 300V
LCV 300V
LCA 1A
LCA 1A
LCA 10A
LCA 10A
Requirements
Measure Range: 0 to 4kV, 0.1% accuracy
Measure Range: 0 to 10mA, 0.15% accuracy
Tool # 01-1395 or equivalent
250V
500V
500V & 1000V; 1200V, 0.1mA, .25W
200W
200W
100W
50W
RANGE
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
-----
-----
Offset
Range 1
Range 2
Range 3
Range 4
Offset
Full
Offset
Full
Offset
Full
Offset
Full
Offset
Full
150799 Rev A3
CAL. POINT
100 V
4.000kV
100 V
4.000kV
100 V
1.000kV
0.12mA
2.5mA
2.5mA
25mA
0.12mA
2.5mA
2.5mA
10mA
3A
25A
0.3V
3V
5mA
5mA
Open
1GΩ
100MΩ
10MΩ
10MΩ
0.08V
0.8V
0.8V
8V
20V
200V
0.08A
0.8A
0.8A
8A
Service & Calibration
