Measurement Mode
The G6100 Plus Electrical Safety Analyzer is capable of measuring AC Hipot, DC Hipot,
Insulation Resistance, Leakage Current and Ground Bond, plus detecting Open/Short
circuits at the test terminals to verify proper connection to DUT.
2.7.3 for the appropriate cable connection to the device under test. Refer to ¶ 2.4.1-2.4.7
for instruction on programming a test.
AC Hipot Measurement Example:
1
2
3
4
5
6
7
8
9
10
11
12
13
[PROGRAM] the AC Example Test
STEP SETTING
01.
02.
03.
04.
05.
06.
07.
08. Test Time
09. Ramp Time
10. CHNL (H-L)
SELECT STEP
www.valuetronics.com
Condensed Operating Instructions (Cont.)
Turn Power ON.
Let Guardian 6100 Plus unit warm-up 15 minutes.
Connect Black ground cable to G6100 Plus DRIVE- terminal.
Connect Red high voltage cable to G6100 Plus OUTPUT terminal.
Press [PROGRAM] and enter the example AC Test Parameters
Zero the G6100 Plus unit (OFFSET, ¶2.7.1).
Perform [GET Cs] (¶2.7.2)
[STORE] Test set-up in Memory menu.
Connect the Device Under Test (DUT).
Press red [STOP] button.
Press green [START] button.
Record Readings.
Press red [STOP] button.
1
Test Step
:
Test Mode
:
AC
1.500 kV
Voltage
:
High Limit
:
0.500mA
OFF
Low Limit
:
OFF
Arc Limit
:
3-230 kHz
Arc Filter
:
:
3.0 sec
3.0 sec
:
OFF
:
Remote
Lock
Offset
QuadTech
Guardian 6100 Plus
STOP
Electrical Safety Analyzer
START
ON
1
0
OFF
Figure COI-3: S02 Cable Connection To Device Under Test
[TEST] Menu
TEST
UP
MODE
01.
AC
DOWN
INSERT
DELETE
Error
1
4
7
0
150799 Rev A3
Refer to paragraph
SOURCE
LIMIT
RES.
OFFSET
1.500 kV
0.500 mA
GET Cs
PAGE UP
PAGE DOWN
SCANNER - 1
1 2 3 4 5 6 7 8
AC __ __
Remote
Lock
Offset
Error
TM
Twin
Por t s
2
3
HIGH
DANGER
VOLTAGE
CAUTION!
!
Max: 5kVAC
5
6
6kVDC
OUTPUT
PASS
FAIL
8
9
.
CLR
Drive
Sens e
Sens e
Drive
+
-
S02 HV Lead Set
(-)
(+)
DUT
GND
HV
