QuadTech Guardian 6100 Plus Instruction Manual page 25

Reference
Number
Figure 1-3
1
a
b
c
d
e
f
g
h
2
3
4
5
6
7
8
9
10
11
12
12
12
12
13
Introduction
www.valuetronics.com
Table 1-2: G6100 Plus Rear Panel Connectors and Controls
Name Type
6000-07 Internal Scanner
N-OUT CH-1 White Banana Plug
L-OUT CH-1 White Banana Plug
#1 Red Banana Plug
#2 Black Banana Plug
N-IN Red Banana Plug
L-IN Red Banana Plug
INPUT FUSE Black screw cap
Fan MW-2510M12C, 0.11A12V
AC Inlet Black 3-prong receptacle
Module and fuse drawer
GROUND Silver Banana Jack/Screw
FAN Fulltech UF80A12 AC120V
50/60Hz, 14/12 W
REMOTE Black 5 screw relay strip
INPUT
REMOTE Silver 9 pin D-Type
Connector
REMOTE Black 6 screw relay strip
OUTPUT
Voltage Red 2-position DIP
Selector Switches (2)
RS232 Black 9 pin D-Type
Female Connector
SCAN Black 25 pin D-Type
Female Connector
GPIB Blue 24 pin connector
DRIVE + Red Banana Jack/Screw
SENSE + Red Banana Jack/Screw
SENSE - Black Banana Jack/Screw
DRIVE - Black Banana Jack/Screw
HV OUTPUT White Female Receptacle
Function
Hipot/Line Leakage Current Scanner
Neutral Output to DUT
Line Output to DUT
Patient Probe #1
Patient Probe #2
Neutral Input (from isolation transformer)
Line Input (from isolation transformer)
T20A 250V SB
Cool scan unit
3-wire connection for AC power source.
Fuse drawer: 8A 250V for 100-120 operation,
4A 250V for 220-240 operation.
Chassis ground connection
Temperature Control Fan to cool unit:
ON ≥50°C, OFF <50°C
Remote input signals : START, RESET, COM &
INTER LOCK
Input signals : START & RESET
Output signals : UNDER TEST, PASS & FAIL
Remote output signals : UNDER TEST, PASS, &
FAIL
Switches for selecting range of AC power source:
Set to 100V for 90-110VAC operation
Set to 120V for 108-132VAC operation
Set to 220V for 198-242VAC operation
Set to 240V for 216-250 VAC operation
Serial Input/Output connections for RS232 Interface
Input/Output connection for EXT Scanner Interface
Parallel I/O connections for IEEE-488 (Optional) or
Printer (Optional)
Rear Panel Output High Current GB Test
Rear Panel Output High Voltage GB Test
Rear Panel Output Low Voltage GB Test
Rear Panel Output Ground Ref. for all Tests
Rear Panel Output Channel 3; Program High or Low
150799 Rev A3 Page 25 of 177
