QuadTech Guardian 6100 Plus Instruction Manual page 66

PA Programming – continued from last page.
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Message
04. Under Test
0 - 13 Characters
Enter Pause Message: "CHANGE LEAD"
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Message
04. Under Test
REAR PANEL OUTPUT
Press the function key [OFF] to set Under Test relay = ON
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___4___ ". STOP.
To continue programming the 7-step example:
Press the function key [UP] to select Test Step = 5. Instructions continued in ¶
OR
To End Programming and review PA mode:
Press [MENU] to exit program mode.
Perform offset (¶ 2.7.1), connect DUT (¶ 2.7.3) then press green [START] button.
Page 66 of 177
www.valuetronics.com
: 4
: PA
NEXT CHAR.
_
:
: ON
Remote Lock Offset
: 4
: PA
ON
CHANGE LEAD
:
ON
:
OFF
Remote Lock Offset
Use Function Key to move cursor to next character
Use Numeric Keys then [ENTER]
Enter the Message: 0 - 13 alpha-numeric characters
PRESS
[1]
[3]
[1]
[5]
[3]
[2]
Error
[4]
[2]
[1]
[2]
Use Function Key
Enter the status of the Rear Panel Output
ON or OFF
Error
150799 Rev A3
4x C [ENTER] [NEXT CHAR]
3x H [ENTER] [NEXT CHAR]
2x A [ENTER] [NEXT CHAR]
3x N [ENTER] [NEXT CHAR]
2x G [ENTER] [NEXT CHAR]
3x E [ENTER] [NEXT CHAR]
_ [NEXT CHAR]
4x L [ENTER] [NEXT CHAR]
3x E [ENTER] [NEXT CHAR]
2x A [ENTER] [NEXT CHAR]
2x D [ENTER]
2.4.5*
Operation
