QuadTech Guardian 6100 Plus Instruction Manual page 76

2.4.7 Programming a Leakage Current (LC) Test
In an LC test, high voltage is applied to the DUT and the resistance is measured between
the DUT insulation and ground. A high limit is required in an LC test. The high limit is
the maximum allowable value for the test to be considered a PASS. If the measured
value is higher than the high limit the test is considered a FAIL.
If not already in PROGRAM mode:
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
If continuing example:
* Press the function key [UP] to select Step # = 7
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT STEP
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT MODE
Press the function key [LC] to select mode = Leakage Current
Continued on next page.
Page 76 of 177
www.valuetronics.com
1
:
: GB
: OFF
100.0m Ω
:
DOWN
: OFF
: 3.0s
: OFF
OFF
:
INSERT
DELETE
Remote Lock Offset
: 7
GB
:
: OFF
100.0m Ω
:
: OFF
: 3.0s
: OFF
OFF
:
PAGE 1/2
Remote Lock Offset
Use Function Key
UP Toggle UP: 1 - 50
Toggle DOWN: 50 - 1
Add a step
Remove a step
Error
Use Function Key
Ground Bond
GB
AC AC Hipot
DC DC Hipot
IR Insulation Resistance
LC
Leakage Current
Go to Page 2 (PA, OSC)
Error
150799 Rev A3 Operation
