LC Programming – continued from last page
Press DOWN arrow [⇓]
STEP SETTING
01.
Test Step
02.
Test Mode
03.
Device
04.
Line Input
05.
GB Switch
06.
Meter
07.
High Limit
08.
Low Limit
09.
Power
10.
Test Time
11.
CHNL (H-L)
PRESS FUNCTION KEY
Press the function key [UL2601] to select device = UL2601 body model
Press DOWN arrow [⇓]
STEP SETTING
01.
Test Step
02.
Test Mode
03.
Device
04.
Line Input
05.
GB Switch
06.
Meter
07.
High Limit
08.
Low Limit
09.
Power
10.
Test Time
11.
CHNL (H-L)
PRESS FUNCTION KEY
Press the function key [NORMAL] to select line input = Normal
Press DOWN arrow [⇓]
STEP SETTING
01.
Test Step
02.
Test Mode
03.
Device
04.
Line Input
05.
GB Switch
06.
Meter
07.
High Limit
08.
Low Limit
09.
Power
10.
Test Time
11.
CHNL (H-L)
PRESS FUNCTION KEY
Press the function key [OPEN] to set the Ground Switch = OPEN
Continued on next page.
