NOTE: If the configuration number has not been saved previously, the
following error message displays:
CONFIG. DOES NOT
EXIST/Save First
If this error message displays, see "Saving A Configuration" on
page 75. Once you have saved a configuration, repeat the steps in
this procedure.

Modifying A Saved Configuration

You can change a saved configuration by rewriting over it. For example, you
can modify Config. 1, shown below. Suppose you want to keep all the settings
but you want to select the parallel Centronics interface instead of the IEEE
1284 interface.
1. Load the configuration to be changed (for example, Config. 1).
. .
a. Press the key until the following message displays:
.
MENU MODE
CONFIG. CONTROL
b. Press the ↓ key until the following message displays:
Load Config.
Factory
c. Press the + or – key to cycle through the options: Factory 1-8.
d. When the desired number displays, press the
following message displays:
Loading Saved
Configuration
Then, the following message displays when it is loaded:
Load Config.
X *
2. Move through the menu and change all the desired values. (In this
example, press the
key until Port Type/IEEE 1284 displays. Press the - key until Centronics
displays.)
↵
3. Press the key to select each new value. An asterisk (*) displays.
Modifying A Saved Configuration
. .
key until PARALLEL PORT displays. Press the ↓
.
↵
key to select it. The
