Sympton
No repeat label after
cylinder is cycled.
Cylinder extension too
short or too long.
Labels not peeling off
onto the tamp pad
assembly.
Table 10. Applicator Troubleshooting Chart
Diagnosis
1. Printer buffer is empty or
the quantity of one was sent
to the print buffer.
2. Check pad home sensor
LED.
3. Check for printer faults.
Check cylinder extend time.
1. Check label tension around
the peel plate.
2. Verify that the labels are not
expired or defective.
3. Verify that the labels are
loaded properly and the
backing motor is operating
correctly.
General Symptom List
Solution
1. Send new quantity of labels
to the buffer.
2. Adjust sensor mount on the
cylinder and tighten or
replace if defective.
3. Correct and clear all faults
on the LCD.
Change Cylinder Extend time
value in the Applicator Delay
menu.
1. Correct the brake
adjustment on the label
supply roll. Replace dancer
spring if worn. Check peel
plate for wear and proper
alignment.
2. Store labels in an area 60 to
80 degrees F at 50 to 60%
humidity. If defective, order
new labels from Printronix.
3. Make sure the labels are
loaded correctly (page 41).
Check motor belt and gear
for wear. Verify that the
dancer proximity is
energizing the 24V relay
and turning on the motor
control circuit.
