Appendix C
Circuit Board And Cable Pinouts
NOTE: Part of the printhead cover.
350
Media Sensor Assembly, Upper
See Figure 49, page 276, item 32.
Wire Table
Pin
1
2
3
4
5
6
7
Signal
Not used
Not used
Not used
Not used
Not used
MG IRED DRIVE
FF RESISTOR
