Printronix SLPA7000 User Manual page 277

Item
Part No.
No.
1 173603-001
173606-001
2 203419-001
3 170383-001
171089-001
4 170382-001
171088-001
5 170298-001
171087-001
6 171458-001
7 203281-001
8 171173-001
172142-001
9 203824-001
10 171746-001
11 170193-001
12 171277-001
13 203513-001
14 173858-001
15 171161-001
16 203251-001
17 171121-001
18 172197-001
19 171458-001
20 172266-001
Description
Field Kit, Printhead Assy, 203 dpi, 4 in
Field Kit, Printhead Assy, 300 dpi, 4 in
Ring, Retaining, E, .188 inch (3)
Dial, Head Pressure Adjustment
Dial, Head Pressure Adjustment
Indicator, Head Pressure Dial
Indicator, Head Pressure Dial
Knob, Lead Screw, SM, .90 in OD
Knob, Lead Screw, LG, 1.15 in OD
Handle, Pressure Pad, 4 inch
Screw, Btn Hd Soc Cap, M3x6mm (7)
Shaft, Head Pressure, 4 inch
Shaft, Head Pressure, 4 inch
Screw, Flanged, Socket Head,
M4x10mm (3)
Sensor, Head Up
Holder, Sensor
Clip, Head Retainer (2)
Screw, Button Head, M3x4mm (7)
Brush Assembly, Anti-Static, 4 inch
Gimbal, Adjustable, 4 inch
Screw, Hx Skt Btn Hd, ZI, M3x8mm (2)
Ground Wire, Antistatic
Rack, Gimbal Pivot, 4 inch
Handle, Pressure Pad, 4 inch
Head Pressure Block Assy, 4 inch (2)
Notes
Includes items 31, 32, and
33. Does not include item 30.
For RFID models, see
Figure 89, page 382, item 3.
Available only in Hardware
Kit 171629-001 (page 316).
Small knob version.
Large knob version.
For small knob.
For large knob.
Small knob.
Large knob. Not on -DT
models.
Not on -DT models.
Available only in Hardware
Kit 171629-001 (page 316).
For small knob.
For large knob.
Available only in Hardware
Kit 171629-001 (page 316).
Right clip not shown.
Available only in Hardware
Kit 171629-001 (page 316).
Not on -DT models.
Not on -DT models.
Available only in Hardware
Kit 171629-001 (page 316).
Not on -DT models.
Not on -DT models.
Not on -DT models.
Not on -DT models.
