Appendix C
Circuit Board And Cable Pinouts
J38
Flash
SIMM
J33
DRAM
SIMM
J21
340
Controller Board
Upper Media Sensor
1
FF RESISTOR
2
MG IRED DRIVE
3
FF RESISTOR
Lower Media Sensor
J15
1
MG LED DRIVE
2
REFL LED SINK
3
MG SENSE COLLECTOR
MG SENSE EMITTER
4
