Item
Part No.
No.
1
750568-001
2
203419-001
3
171403-001
4
204002-001
5
203251-001
6
173179-003
7
175330-001
8
175286-001
9
203824-001
Description
Gear, Ribbon Drive, Intermediate
Ring, Retaining, E
Field Kit, DC Motor
Screw, Flanged, Socket Head,
M4x12mm (2 per motor)
Screw, Hx Skt Btn Hd, ZI, M3x8mm (6)
Plate, Rear Panel
Plate, I/O, Blank, Wide
Plate, Parallel, Blank
Screw, Flanged, Socket Head,
M4x10mm (6)
Notes
Not on -DT models.
Available only in Hardware
Kit 171629-001 (page 316).
Does not include item 4.
Not on -DT models.
Not part of item 3. Available
only in Hardware Kit
171629-001 (page 316).
Available only in Hardware
Kit 171629-001 (page 316).
Fits items 6 and 6a.
Fits items 6 and 6a.
Available only in Hardware
Kit 171629-001 (page 316).
