Item
Part No.
No.
1
B5605-502
2
178518-001
3
F0032-006
4
F0032-008
5
F0076-011
6
F0153-006
7
H0038-028
8
H0051-255
9
H0053-154
10
H0054-195
11
H0054-196
12
P0010-037
13
PF001-004
14
PF003-007
15
PF003-008
16
PF010-003
Description
Media Roller Sub-Assembly
Brake Pad
Brake Shaft
Spring Post
Block
4601 Brake Arm
Ring Ret. Ext. Ser. 5100 0.375 D
FHSCS #10-32x0.500 Lg
BHCS #6-32x0.375 Lg
SHCS #8-32x0.500 Lg
SHCS #8-32x0.625 Lg
Extension Spring 3.25 Lg
Ball Bearing 0.375 ID x 0.875 OD
Sleeve Bearing 3/8 inch ID x
7/16 inch OD x 3/8 inch Long
Thrust Bearing, Bronze 3/8 ID 3/4 OD
x 0.06 Thk.
Spring Anchor 8-32 Thds.
Notes
