Example 2: Uneven Number Case
Problem: A file has been constructed with three horizontally adjacent 2"
labels. The user now desires to use this file with a printer that has a 4"
physical width.
Solution #1: The user sets Auto Label Width to 4" (the width of two labels),
configures the Num Auto Labels to 2, and enables the Auto Label Mapping
feature.
Printer Operation for Solution #1: The printer will print the first two labels at
the same time. These first two labels will be horizontally adjacent. Once these
labels have been completed, the printer will print the remaining 2" labels along
with a blank 2" label.
File Contents:
Label
Label
1
2
Solution #2: The user sets Auto Label Width to 2", configures the Num Auto
Labels to 3, and enables the Auto Label Mapping feature.
Printer Operation for Solution #2: The printer will print the first 2" label by
itself, the second 2" label by itself, and finally, the last 2" label by itself.
Label
Label
1
2
MEDIA CONTROL Submenus
Print Output:
Label
Label
1
3
Label
3
Label
Label
3
Label
Label
Label
2
Blank
Label
1
2
3
