Chapter 3
GPIO CONTROL Menu

GPIO CONTROL Submenus

GPIO
Enables the use of the GPIO hardware.
•
Disable. The default.
•
Enable.
GPIO Tables
NOTE: This menu appears only if a user-defined table is downloaded to the
Allows you to select a mapping table.
•
Internal. The default. The standard internal mapping table.
•
User Defined. The user-defined mapping table.
GPIO Sel. Table
NOTE: This menu appears only if a user-defined table is downloaded to the
These submenus are dynamic and can vary from user to user. See your
system integrator for details.
GPIO Start Print
NOTE: This menu appears only if an internal table is selected or if there is no
Start print logic.
•
Input Low. The default. Start print when input asserts low.
•
Input High. Start print when input asserts high.
GPIO End Print
NOTE: This menu appears only if an internal table is selected or if there is no
Mode selectable via the printer menu.
NOTE: End print applies only to printed labels. Output remains in normal
•
Mode 1. The default. Normally high. Low only when a label is being
moved forward.
•
Mode 2. Normally low; high only when a label is being moved forward.
•
Mode 3. Normally high; low for 50 milliseconds when a label has been
printed and positioned. Always high during continuous printing modes.
•
Mode 4. Normally low; high for 50 milliseconds when a label has been
printed and positioned. Always low during continuous printing modes.
150
printer.
printer.
user-defined table.
user-defined table.
state for blank labels.
