Gear, Ribbon Drive, Intermediate

Removal
1. Prepare the printer for maintenance (page 223).
2. Remove the appropriate final ribbon drive gear (page 232).
3. Remove the appropriate DC ribbon drive motor (page 242).
4. Remove the retaining E-ring securing the intermediate ribbon drive gear
to the shaft. (Figure 52, page 286, items 1 and 2.)
5. Remove the intermediate ribbon drive gear from the spindle shaft.
Installation
1. Put a dab of grease in the bore of the intermediate gear then reverse the
steps of the removal procedure.
2. Restore the printer to operation (page 224).

Gear, Ribbon Drive, Intermediate

233
