Printronix SLPA7000 User Manual page 269

Item
Part No.
No.
1 171409-001
171408-001
172264-001
2 750569-001
3 203278-001
4 178614-001
178614-002
178614-003
4a 171407-001
171406-001
172263-001
5 750641-001
6 203480-001
203479-001
203478-001
7 203510-001
8 203523-001
9 203526-001
10 204527-001
11 174494-001
12 203513-001
13 170528-001
14 105678-003
15 203403-001
16 Ref
Description
Field Kit, Ribbon Spindle, 8 inch
Field Kit, Ribbon Spindle, 6 inch
Field Kit, Ribbon Spindle, 4 inch
Gear, Ribbon Drive, Final
Ring, Retaining, E, .375
Spares Kit, Rewinder, V3, 8 inch
Spares Kit, Rewinder, V3, 6 inch
Spares Kit, Rewinder, V3, 4 inch
Field Kit, Rewinder, 8 inch
Field Kit, Rewinder, 6 inch
Field Kit, Rewinder, 4 inch
Spring, Media Damper
Take-up Core, 8 inch
Take-up Core, 6 inch
Take-up Core, 4 inch
Washer, Nylon, .750x.443x.032
Washer, Nylon, .380x.683x.031
Washer, .390x.656x.020
Washer, Nylon, 1.125x.500x.080 inch
Pulley Assy, Rewinder
Screw, Btn Hd, M3x4mm (2)
Blade, Ribbon Spindle
Ring, Retaining, E, .3125
Screw, Set, 8-32x.375 (2)
Media Damper Stop
Notes
Includes items 3, 7, 12 and
13. Not used on -DT models.
Not used on -DT models.
Part of item 1. Available only
in Hardware Kit 171629-001
(page 316).
Includes items 7, 10, 11, and
14. Rewinder option.
Replace with 178614-001.
Replace with 178614-002.
Replace with 178614-003.
Additional core required
when using thermal ribbon.
Not used on -DT models.
Part of items 1 and 4. Also
available in Hardware Kit
171629-001 (page 316).
Available only in Hardware
Kit 171629-001 (page 316).
Available only in Hardware
Kit 171629-001 (page 316).
Part of item 4. Also available
in Hardware Kit 171629-001
(page 316).
Part of item 4. Use with the
rewinder option only.
Part of item 1. Available only
in Hardware Kit 171629-001
(page 316).
Part of item 1, but can also
be ordered separately. Not
on -DT models.
Part of item 4. Also available
in Hardware Kit 171629-001
(page 316).
Also available in Hardware
Kit 171629-001 (page 316).
269
