Part No.
203526-001 Washer, .390x.656x.020
203527-001 Clip, EMI
203590-001 Grommet, Hole
203643-001 Plug, Frame, .5 inch
203662-001 Nut, Locking, M10
203682-001 Plug, Frame, .4375 inch
203711-001 Screw, Captive, Btn Hd, M4x10mm
203824-001 Screw, Flanged, Socket Head, M4x10mm
204002-001 Screw, Flange, Soc Hd, Bk, M4x12mm
204014-001 Screw, Button, Socket Head, SS, M5x10mm
204527-001 Washer, Nylon, 1.125x.500x.080 inch
750923-001 Button, Damping
Description
Hardware Kit
Qty Notes
2
3
4 For DC and stepper
motors.
2 Frame plugs.
1
2 For 4 inch rewinder hole.
2 Use to fasten frame side
cover.
10
2
2
1
3
