Appendix D
Flash Memory
Downloading Software Through the
Serial or Parallel Port
1. Make a printout of all saved configurations. (Installing new software
erases all saved configurations. You will use the printouts to restore the
printer configurations.)
2. Set the printer power switch to O (Off).
3. If the printer is already connected to the serial or parallel port of an
IBM-compatible computer running the Microsoft Windows (95, 98, Me,
NT, 2000, or XP) operating system, go to step 9. If not, go to step 4.
4. Unplug the AC power cord from the printer.
5. Disconnect all data input cables from the printer interfaces.
6. Connect a parallel data cable to the LPT1 port or a serial data cable to the
COM1 port of an IBM-compatible computer running the Microsoft
Windows (95, 98, Me, NT, 2000, or XP) operating system.
NOTE: You can connect the cable to the LPT2 port if the LPT1 port is already
7. Connect the data cable to the appropriate I/O port of the printer.
8. Plug the AC power cord into the printer.
9. On the printer control panel, press and hold down the
Without releasing the keys, power the printer on. Continue holding down
the
10. When you see "TESTING HARDWARE PLEASE WAIT" on the LCD,
release the
11. Wait until you see "WAITING FOR PROGRAM DOWNLOAD" on the LCD
before proceeding. This can take up to 30 seconds to appear, depending
on the emulations and interfaces installed in the printer.
12. Press the + key. "SELECT DOWNLOAD PORT=CENTRONICS" appears
on the LCD.
NOTE: The default port is CENTRONICS; this is the standard load through
13. Press + again to cycle through the download ports available in the printer:
RS232-9600 (RS-232 serial, 9600 baud)
RS232-19.2K (RS-232 serial, 19200 baud)
RS232-38.4K (RS-232 serial, 38400 baud)
RS232-115K (RS-232 serial, 115000 baud)
RS422-9600 (RS-422 serial, 9600 baud)
RS422-19.2 (RS-422 serial, 19200 baud)
RS422-38.4K (RS-422 serial, 38400 baud)
RS422-115K (RS-422 serial, 115000 baud)
DEBUG
352
in use. The load commands are different if you use this port, as
described in the note after step 22.
. .
and ↓ keys.
.
. .
and ↓ keys.
.
the parallel port. If you want to use the default, continue at step 14.
. .
and ↓ keys.
.
