Symptom
•
Label(s) did not get
printed within a multi label
print job.
•
A portion of the printed
image was clipped off
and the beginning of the
next label was printed on
the same physical label.
Short printhead life.
Media moves, but no image
prints in ONLINE mode.
Media moves, but no image
prints in Direct Thermal
mode.
Table 9. General Symptom List
PRINT QUALITY
1. If the serial interface is being used, verify that the correct
data protocol is selected to match the host interface
protocol.
2. If Clip Page = Enable in the MEDIA CONTROL menu, the
printer may have falsely detected a gap, hole, or black
mark and then clipped (discarded) the remaining printable
data for the label. To fix this:
a. Perform Auto Calibrate. See "Running Auto Calibrate"
on page 63.
b. Decrease Gap Threshold value by 2 or 3 increments.
See "Gap/Mark Sensor" on page 93.
c. Set Clip Page to Disable. Set Label Length to correct
physical length value. Refer to "Clip Page" in the
User's Manual .
See "How To Maximize Printhead Life" on page 159.
1. Print a checkerboard diagnostic test pattern (page 163). If
the pattern prints, there is a communication problem
between the host computer and the printer.
2. Make sure the J402 power supply cable has a good
connection to the right side of the printhead.
1. Print a checkerboard diagnostic test pattern (page 163).
Check the print quality.
2. Media is not the type for Direct Thermal printing. Install
Direct Thermal media.
3. Direct Thermal media is installed with the wrong side up.
Reinstall media.
4. Check that the Label Width value in the QUICK SETUP or
MEDIA CONTROL menu does not exceed the media width
installed.
5. Check that the Print Intensity value is not set too high in
the QUICK SETUP or MEDIA CONTROL menu.
6. Check that the printhead assembly is properly closed by
pressing down on both sides of the pivoting deck. Make
sure the latches on each side of the pivoting deck are
locked.
7. The head pressure adjustment dial may be set too low.
Readjust.
8. The printhead pressure blocks are not positioned correctly
(horizontally). Refer to the User's Manual .
General Symptom List
Solution
