Chapter 6
Removal And Replacement Procedures

Access Panels

Removal
1. Prepare the printer for maintenance (page 223).
2. Remove the two screws securing the small access panel.
3. Slide the small access panel out of the SLPA.
4. Remove the screw securing the large access panel.
5. Slide the large access panel out of the SLPA.
Installation
1. Reverse the steps of the removal procedure.
2. Restore the printer to operation (page 224).
226
