Start Here

Are you here because of an
error message?
NO
Power on the printer and
observe the control panel for
the following sequence of
events (retry as required):
1. TESTING HARDWARE
PLEASE WAIT appears on
display.
2. DIAGNOSTICS PASSED
appears on display.
3. LOADING FONTS FROM
FLASH appears on display.
4. Printer goes ONLINE or
OFFLINE, depending on
user's configuration.
Did steps 1 through 4 occur? YES
NO
Is the control panel display
backlit?
NO
Go to Printer fails to turn
on, the display is not
backlit, and the fan is not
running, page 202.
Go to Troubleshooting
YES
Display Messages,
page 164.
Make a configuration
printout. (Refer to
the User's Manual .)
Does machine
configuration print?
NO
Go to LCD message
display is illuminated
and the printer
appears to be
working, but nothing
is printed, page 201.
Is there a faint
YES horizontal bar on the
display?
NO
1. Power down, remove
frame side cover, and
reseat control panel cable.
2. Replace control panel
and cable.
3. Troubleshoot using Half-
Split Method outlined on
page 162.
Troubleshooting At A Glance
Is this a newly
YES
installed printer?
NO
IML was
successful. Other
symptoms are
listed in Table 9,
page 199.
Go to Printer does not
YES initialize, the display is
backlit and a faint
horizontal bar appears on
the top line. No message
displays, page 202.
YES
Go to
Troubleshooting
A New
Installation,
page 221.
161
