Removal And Replacement Procedures
RP1
Default: 1K Ohm
Alt 1: 330 Ohm
Alt 2: None
Figure 44. This figure shows the size and location of the terminating resistors on the
254
RP2
Default: 470 Ohm
Alt 1: 220 Ohm
Alt 2: 1K Ohm
controller board.
