Appendix F

Replace The RFID Antenna And Encoder Assemblies

Replace The RFID Antenna And Encoder Assemblies
Use these instructions to replace either assembly; you do not have to replace
both assemblies at the same time.

Remove the RFID Encoder Assembly

Figure 81. Removing the RFID Encoder Assembly
1. Loosen the captive thumb nut. (Figure 81.)
2. Lift the RFID encoder assembly off the two mounting studs and remove
the assembly.
370
Mounting Stud (2)
Captive
Thumb Nut
RFID Encoder
Assembly
