Printronix SLPA7000 User Manual page 313

Item
Part No.
No.
178499-901
1 F0058-002
2 F0061-502
3 F0147-019
4 H0054-277
5 H0110-049
6 H0132-094
7 H0132-125
8 H0135-004
9 H0135-024
10 H0135-025
11 P0027-071
12 P0038-523
13 PF029-019
14 178519-001
Description
Cylinder Assy, Swing, 14 inch/356 mm
Cylinder Cover, 14 inch
Solid State Swith Assy, 14 inch
Cylinder Bracker, 20 mm
SHCS 1/4-20x0.750 Lg
Washer Splitlock 0.250
BHCS M5x0.08x10mm Lg
BHCS M6x1.00x20mm Lg
FW M5 SS
LW M5 SS
Fastener M6 Lock Washer SS
Pinch Point Warning Label
1/4 Tube 1/8 NPT Elbow
Washer 1/4 inch (grade 8 steel)
Slide Assembly 350 mm Stroke
Notes
Includes all items shown in
Figure 65.
313
