Chapter 6
Removal And Replacement Procedures
The STAT (Status) Indicator In Run And Auto Reset Modes
Run Mode is the normal operating state of this interface. Auto Reset mode is
entered when the watchdog timer is triggered and the print server resets itself.
In either mode, the STAT LED flashes at a varying rate, depending on
whether the unit IP address is configured. The Run Mode and Auto Reset
Mode indicator descriptions are shown in Table 12.
NET (Network) Indicator
The NET LED displays the status of the network link:
NET LED
246
Table 12. STAT LED
STAT Rate
OFF Flashes ON once per
second
OFF Flashes ON 2 times
per second
ON Flashes OFF once
per second
ON Flashes OFF twice
per second
Table 13. NET LED
Rate
ON Constantly
ON Flashes OFF 1/3
second
OFF Constantly
Indication
Normal Mode, IP address
configured
IP address not configured
Download mode
Error
Indication
Indicates link integrity
Flashes off 1/3 second every time
a packet is transmitted
Network connection has been
severed
