Appendix
Beacon Package Options
Fault/Warning Beacon Package
This option provides a blue and an amber beacon tower that is connected to
the SLPA. The blue/amber lights are used to convey fault/warning information
in this package, as follows:
•
Fault: An illuminated blue beacon signals a fault situation. Fault
conditions (such as Out of Label) signal a state where operation is
suspended until the condition is cleared.
•
Warning: An illuminated amber beacon signals a low label situation. This
signal state allows operation to continue, but the operator is prompted to
check the system's status.
Pneumatic Monitor Package
The Pneumatic monitor package is comparable to the Fault/Warning beacon
package (see "Fault/Warning Beacon Package" on page 326) but contains
additional parts and software to monitor the input pressure of the SLPA.
NOTE: An input pressure error occurs if the input pressure to the SLPA falls
The blue/amber lights are used to convey fault/warning information in this
package, as follows:
•
Fault: An illuminated blue beacon signals a fault situation. Fault
conditions (such as Out of Label) signal a state where operation is
suspended until the condition is cleared.
•
Warning: An illuminated amber beacon signals a low air pressure or low
label situation. Warning conditions signal a state where operation may
continue, but the operator is prompted to check on the system's status.
Fault/Warning Beacon Package With Interface Module
This option provides the same abilities as the Fault/Warning beacon package
(see "Fault/Warning Beacon Package" on page 326), but also includes the
remote signal ability of the Interface package.
Pneumatic Monitor Package With Interface Module
This option provides the same abilities as the Pneumatic monitor package
(see "Pneumatic Monitor Package" on page 326), but also includes the
remote signal ability of the Interface package.
326
out of the specified range.
