Orientation
Specifies the image orientation to be used when printing the label.
•
Portrait. The default. Portrait refers to vertical page orientation, where the
height of a page is greater than its width. The top edge of the image is
parallel to the leading edge of the media. The following example is viewed
from the front of the printer.
NOTE: Portrait orientation applies to PGL
regarded as Inverse Portrait using PPI1.
4 inches
FEED
media.
of
edge
the
to
is
of
edge
Leading Edge
•
Landscape. Landscape refers to horizontal orientation, where the width
of a page is greater than its height. The top edge of the image is parallel
to the left edge of the media. The following example is viewed from the
front of the printer.
NOTE: Landscape orientation applies to PGL and VGL emulations. This is
regarded as Inverse Landscape using PPI1.
4 inches
FEED
Leading Edge
®
and VGL emulations. This is
6 inches
the
leading
parallel
the
top
The
6 inches
QUICK SETUP Submenus
91
