Operator Panel

Figure 20 Operator Panel
Status indicator
Robotics Enabled
indicator
Robotics Enabled
button
Quantum Scalar i6000 User's Guide
The operator panel is located on the front of the control module and
consists of indicators and a touch screen (see
are for library control and power, and the indicators provide library
status.
The touch screen is the library navigation point and provides access to
the LMC. For more information about the touch screen and the LMC,
see Library Management Console (LMC)
Chapter 1: Description
Operator Panel
Figure 20). The buttons
Power indicator
Power button
touch screen
on page 442.
37
