Quantum Scalar i6000 User Manual page 125

Figure 31 Locations of LBX
Terminator LEDs (Version 03)
Table 19 Explanations of LBX
Terminator LED States (Version
03)
LED On/Off Combinations
1 2 3 4
Off Off Off Off
On Off Off Off
On Off Off On
On Off Off On
On Off Off On
On Off Off Off
Quantum Scalar i6000 User's Guide
LBX Terminator Version 03 LEDs
The LBX terminator has six green LEDs that indicate the presence of
modules in the library.
Table 19 on page 107 describes how to interpret LED activity on the LBX
terminator.
1
5 6 Explanation
Off Off Robotics are disabled, the access door is open, or the LBX
terminator is misaligned.
Off Off The library has one control module and no expansion modules.
Off Off The library has one control module and one expansion module.
On Off The library has one control module and two expansion modules.
On On The library has one control module and three expansion modules.
On On The library has one control module and four expansion modules.
Chapter 2: Troubleshooting Your Library
Figure 31 shows the locations of the LEDs.
2 3 4
Interpreting LEDs
5 6
107
