Chapter 1: Description
I/O Management Unit
Figure 16 I/O Management
Unit in Series 3 Module
Bay 1 - Not used
Bay 3 - FCB or EEB
Bay 5 - FCB or EEB
Bay 7 - EEB
CMB = Control Management Blade
FCB = Fibre Channel I/O Blade
EEB = Ethernet Expansion Blade
24
Bay 2 - CMB
Bay 4 - FCB or EEB
Bay 6 - FCB or EEB
Bay 8 - EEB
Quantum Scalar i6000 User's Guide
