Operator Panel

Quantum Scalar i6000 User's Guide
1 Type or select the library server name or library IP address, and click
OK. You can use either iPv4 or iPv6 addresses.
Once you have connected to additional libraries, you can choose any
of those libraries from the Connection drop-down list.
Note: To log off when connected to multiple libraries, first log off
from one of the connected libraries. To do this, select the
library on the Connection menu, click Operations > Log Off,
and then click Yes. When the Scalar i6000 Logon dialog box
appears, click Cancel. You can then repeat this process to log
off from additional libraries.
The operator panel on the library includes an indicator panel and a
touch screen, as shown in
Chapter 13: Running Your Library
Figure 45.
Operator Panel
439
