Figure 57 I/O Management
Unit Bay Numbering
Table 41 FC I/O Blade/EEB
Location Coordinates
Quantum Scalar i6000 User's Guide
• Bay — The bays in the I/O management unit as viewed from the rear
of the library. There are eight bays in the I/O management unit. Bay
1 is on the lower left and is not populated. Bay 2 always contains
the control management blade (CMB). Bays 3 through 6 can contain
FC I/O blades and bays 7 and 8 can contains Ethernet Expansion
blades. See Figure
cooling assembly
Table 41 lists the range of possible FC I/O blade or EEB location
coordinates.
1 1-16
Aisle Module
Chapter 13: Running Your Library
Understanding Location Coordinates
57.
1
Rack
1 3-8
Cluster Bay
