Quantum Scalar i6000 User's Guide
You can view results for the five most recent tests. Click Reports, and
then click the test results you want to view.
This log file is appended with data as each test finishes. You can repeat
the test if any problems are found and fixed. If the Verification Tests
dialog box was not closed during the retesting, all results are contained
in one log file.
To save the information that the test generates, click Send. If you are
using the remote LMC client, you can choose to save the log to your
hard drive. If you choose to save directly to your hard drive, the report
listing and test log are combined into one text file.
Figure 77 on page 646 shows an example of a test log. It provides the
following information:
• The test output is from the library alignment test.
• In dual-robotics libraries, the test output is for the robot on which
the test was run (the currently active robot).
• The test title is always shown between rows of equal signs.
• A brief guide for understanding coordinates and offsets used in the
test results is provided near the beginning of the log.
• The X-axis and Y-axis limits applied by this test are shown. FAILED
output is placed between brackets; for example, (30) and [45].
• The results of the subtest appear between dashed lines.
• Coordinates are represented as A (aisle), F (frame), R (rack), S
(section), C (column), and R (row).
• All location values are in 0.1 mm.
• All results that you should review are identified with four arrows
(>>>>) in the column to the left of the detailed results.
• At the end of every test, summary results of every subtest are given.
The overall test result appears between asterisk lines, and a
summary of subtest results follows. See
Chapter 15: Maintaining Your Library
Maintenance Actions
Figure 77 on page 646.
645
