Chapter 15: Maintaining Your Library
Maintenance Actions
600
Note: During the configuration teach process, the library runs the
calibration teach process. Afterwards, it automatically performs
an inventory.
1 Log on as an administrator.
2 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
3 Click Tools > Teach. The Teach dialog box appears.
Note: If the physical library is not offline, you receive a message
that asks you whether you want to take it offline. Click Yes.
Configure is already selected by default.
4 Click Start.
During the configuration teach process, the picker moves to each
storage magazine, I/E magazine, and drive in the library and stores
information about them. Teach results appear in the Results text
box when the process completes.
Running Calibration Teach
Starting the calibration teach process causes the library to assess the
position and alignment of various library components through the use
of calibration targets. Use this process to avoid cartridge-handling
problems caused by rack, drive, or I/E station misalignments.
Rack alignment calibration targets are tabs that are located on special
magazines. I/E station targets are small square holes that are located at
the top and bottom of the I/E station. Whenever you perform work on
the library that could affect the position of rack, drive, or I/E station
